FEATURES
 Lightweight and compact design Allows easy installation
 Automatic upper limit switch When rope disc touches the limit arm、hoisting is automatically stopped
 Dynamic and mechanical brakeProvides instant and safe braking
 Can operate on standard domestic power supply
 Come Chiyeh with 4.5 m power lead and industry plug
 Come Chiyeh with 6 m pendant control
 Wire rope with safety hook
 360o weight hook with safety latch

SPECIFICATION
Lifting Capacity (top layer) kg: 195
Lifting Speed m/min: 12 ~ 18
Motor Output 110V kw x A : 1.25 x 12
Motor Output 220-240V kw x A: 1.25 x 6
Motor Type: series wound
Brake : mechanical ratchet
Lifting Height m: 29
Wire Rope Φ mm×m: 5 x 30
Percentage Duty Cycle: 25% ED

WARNING
Winches are not to be used for the moving of persons

WARRANTY
Each new winch is guaranteed against defects in workmanship and material defects for a period of twelve months from date of purchase

DIMENSIONS (mm)

STANDARD ACCESSORIES
 5 mm x 30 m wire rope and hook  K-10
 Pendant control K160A

PACKAGE
 Winch Weight : 17 kg
 Gross Weight : 24 kg
 Box Dimension : 500 x 250 x360 mm
